OZAK 500E Waist Height Turnstile

  • Entry level
  • single leg tripod turnstile
  • pedestrian access control
  • medium level security



Ozak Saudi 500e (Made in Turkey) waist height turnstile  in best price all over Saudi Arabia by Autogateme.  We especially supply in Riyadh, Jeddah, Dammam, Khobar, Makkah, Madinah, Taif, Tabuk and other parts of KSA.

AutoGateMe is leading ozak turnstile supplier and installer of OZAK  model such as 500ED, 500e, 700 r n1 and other waist height and full height turnstile speed gate, flap gate barrier, mantrap gate. We also supply Came, Zkteco waist height, full height turnstile, speed gate, flap gate barrier, mantrap gate all over Saudi Arabia. We are leading Turnstile supplier, Spare parts supplier, installer in all over KSA.

Get reliable site access security with Ozak waist-height Turnstile the best in class and security. We provide complete access control system, and Authorized access by means of Fingerprint, cards or manually. Ozak turnstile is manufactured to install indoor and outdoor (IP 54 outdoor rated), which can be used for any number of passages with uninterrupted operation.  Up to 25 to 46 pedestrians per minute can go through the turnstile in free access mode.

Ozak Turnstile 500E Technical specification:

Power Requirements: 110/220-240 V. 60/50 Hz. AC (%±10) 24 V. DC at standby ~4,4 W. max. ~12 W.

Arms : Ø40 mm x 2 mm 304-grade stainless steel (Opt. 316 – grade stainless steel).

Body Features: 304-grade (Opt. 316-grade) stainless steel with brushed (Opt. satin) surface.

Operation Temperature: -20°C to +68°C (Opt. -50°C with heater unit)

Humidity : RH 95% non-condensing

IP Rating: IP 54 outdoor model (Opt. IP 56)

MCBF :1M cycles.

Emergency Mode: System allows free passage in emergency mode and in case of power failure.

Manual system: max. 97 passages/minute, nominal: ~20 passages

Motorized system: max. 48 passages/minute, nominal: ~16 passages/minute
