Came ZT6/ ZT6C Control board for BK 2200 BY 3500T

Came ZT6/ ZT6C Control board for BK 2200 BY 3500T

  • Control panel compatible with BK2200 & BY3500
  • Multi function control panel for two leaf swing gates
  •  Featuring self diagnosis of safety devices
  • With safety block and buttons (ZT6C)
  • Description

Description

Came Sliding Gate Spare Parts BK 1800, BK 2200, BY 3500T control board in Saudi Arabia by Autogateme

Single and tri-phase 230 V AC or 400 V AC tri-phase power supply. The control panel is protected by a 8 A fuse, while the low voltage accessories (24 V) are protected by a 2 A fuse. The ZT6C control panel comes with safety block and 3-hard wired buttons (stop, open, close) on the case cover. Warning! The overall power of the 24 V accessories must not exceed 20 W.

The card provides and controls the following features:
– automatic closing;
– partial opening for pedestrian passage;
– obstacle detections when gate is not moving at any point;
– maintained action;
– Pre flashing by the flashing light;
– Running the safety test feature.
The available command modes are:
-opening/closing;
-opening/closing with maintained action;
– open-stop-close-stop;
– Partial opening;
– total stop.
The photocells, after detecting an obstacle, may trigger:
– the reopening of the closing gate;
– the reclosing of the opening gate;
– a partial stop;
– a total stop.
Specific trimmers regulate:
– the working time for automatic closing;
– the partial opening time.

BK 2200 Bk1800 BY 3500T TECHNICAL DATA
Power supply 230 V / 400 V – 60 Hz
Maximum power rating 780 W
Power draw when idle 50 mA
Maximum power for 24 V
accessories 45 W
Maximum power for 230 V
accessories 85 W
Circuit insulation class
Container material ABS
Protection rating of the container:  IP54
Working temperature: – 20 / +55°C

The AutoGateMe is leading automatic gates supplier in Saudi Arabia.  Came Sliding Gate Spare Parts supplier in Saudi Arabia.  we Offer Came Sliding gate BK1800, BK2200, BY3500T in Saudi Arabia. Cities such as Dammam, Khobar, Jizan, Qatif, Tabuk, Abha, Madinah, Makkah, Taif etc.  Came all kits come with a full guarantee. We also offer ‘Best Price in the Kingdom’ on all Came automatic gates kits so you can buy from us with confidence.
