Came BKV2500 Sliding Gate – Up to 2500 KG
- Made in Italy
- Protection rating (IP): 54
- Power supply (V – 50/60 Hz): 230/400 V AC TRIFASE
- Power supply to motor (V): 230/400 V AC TRIFASE
- Power (W): 1000
- Operating temperature (°C): -20 ÷ +55
- Motor’s heat protection (°C): 140
- Description
Description
CAME sliding gate kit BKV2500 in Saudi Arabia by Autogateme
CAME BKV 2500kg Sliding Gate kit is designed, built, and tested for intensive duty on large gates, weighing up to 2500 Kg and measuring up to 20m.
Technical Specifications:
| MODELS CODE | 801MS-0300 | 801MS-0310 | 801MS-0320 | 801MS-0350 | 801MS-0360 | 801MS-0370 | 801MS-0330 |
| Protection rating (IP) | 44 | 44 | 44 | 44 | 44 | 44 | 44 |
| Power supply (V – 50/60 Hz) | 230 AC | 230 AC | 230 AC | 230 AC | 230 AC | 230 AC | 120 AC |
| Power supply to motor (V) | 36 DC | 36 DC | 36 DC | 36 DC | 36 DC | 36 DC | 36 DC |
| Absorption (A) | 8 | 9 | 10 | 8 | 9 | 10 | 8 |
| Manouvering speed (m/min) | 12 | 12 | 12 | 12 | 12 | 12 | 12 |
| Duty/cycle (%) | HEAVY-DUTY SERVICE |
HEAVY-DUTY SERVICE |
HEAVY-DUTY SERVICE |
HEAVY-DUTY SERVICE |
HEAVY-DUTY SERVICE |
HEAVY-DUTY SERVICE |
HEAVY-DUTY SERVICE |
| Power (W) | 200 | 250 | 300 | 200 | 250 | 300 | 200 |
| Thrust (N) | 800 | 900 | 1000 | 800 | 900 | 1000 | 800 |
| Operating temperature (°C) | -20 ÷ +55 | -20 ÷ +55 | -20 ÷ +55 | -20 ÷ +55 | -20 ÷ +55 | -20 ÷ +55 | -20 ÷ +55 |
About Came sliding gate:
Ideal solution for applying to sliding gates at busy venues or industrial entrances.
– Range designed for high-performance and functionality in complete safety, for a variety of uses, even industrial, and continuous duty.
– All BKV motors feature the new “Adaptive Torque Technology” to ensure lasting, smooth, constant speed during movement.
– Control board, with separate terminal board and graphical display, for simpler installing and diagnosing. Can store up to 250 users.
– Set up to fit the 806SA-0120 control board for managing up to eight settings.
– On-board Rolling Code and (Twin) Key Code radio-frequency decoding.
– It manages RIO System 2. 0 wireless safety accessories via the 806SS-0040 accessory.
– The R800 accessory lets you directly manage CAME keypads, while the R700 lets you connect CAME transponder selectors.
– “Clock” function for timed management to open and close the gate.
Automated operator featuring a control board with programming display, on-board radio decoding and mechanical limit-switches for sliding gates up to 2,500 kg in weight and 20m in length.
Module 6 pinion
CAME BKV 2500 Sliding gate motor distributors in Saudi Arabia, Riyadh, Jeddah, Khobar, Jizan, Tabuk, Taif, Makkah, Madinah, and other parts of KSA. Call us for CAME BK sliding gate motor/ operator in Saudi Arabia.
Autogateme is the leading supplier of sliding gate operators, spare parts suppliers, and installers all over KSA.
Contact us today by email: info@autogateme.com or Call/whatsapp us +966540075656
